STANDARD SPECIFICATIONS
- RAL 7035 color
- Rapid graft connection
- Tool-free clip installation on 1 to 3.7mm thick sheet metal depending on size
- Heat-bonded synthetic fiber filter with progressive structure
ON REQUEST
- Degree of protection IP55 type 1
- UL Type 3R Degree of Protection
- EMC Shielding
Swipe left to see all the data
| Vacuum ventilation | Filter | Outside dimensions
(mm) | Filter depth
(mm) | Air capacity | Voltage - Frequency | Power absorption | Power | Noise | Temperature | Certification |
||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Code | Code | L | H | P | mc/h | V - Hz | A | W | Db | °C | / | |
| FX 10-01230 A | FF 10 | 107 | 107 | 60 | 12 | 12/15 | 230 ac 50/60 Hz | 0.062/0.050 | 10/8.0 | 33.0/38.0 | -10 +55 | CE - cURus - cULus - CCSAus |
| FX 10-01110 A | 107 | 107 | 60 | 12 | 16/21 | 115 ac 50/60 Hz | 0.113/0.092 | 9.0/7.0 | 33.0/38.0 | -10 +55 | CE - cURus - cULus - CCSAus | |
| FX 10-0124 A | 107 | 107 | 47 | 12 | 16 | 24 DC 50/60 Hz | 85 | 2.0 | 30 | -10 +55 | CE - cURus - cULus - CCSAus | |
| FX 15-04230 A | FF 15 | 150 | 150 | 66 | 22 | 45/50 | 230 ac 50/60 Hz | 0.110/0.100 | 18/17 | 49.0/49.0 | -10 +55 | CE - cURus - cULus - CCSAus |
| FX 15-04110 A | 150 | 150 | 66 | 22 | 45/50 | 115 ac 50/60 Hz | 0.200/0.180 | 16/15 | 46.0/49.0 | -10 +55 | CE - cURus - cULus - CCSAus | |
| FX 15-0424 A | 150 | 150 | 66 | 22 | 47 | 24 DC 50/60 Hz | 310 | 7.4 | 42.5 | -10 +55 | CE - UR - cULus - CCSAus | |
| FX 20-08230 A | FF 20 | 204 | 204 | 88 | 23 | 100/110 | 230 ac 50/60 Hz | 0.106/.100 | 18/18 | 46.0/49.0 | -10 +55 | CE - cURus - cULus - CCSAus |
| FX 20-08110 A | 204 | 204 | 88 | 23 | 100/110 | 115 ac 50/60 Hz | 0.213/0.202 | 19/18 | 46.0/49.0 | -10 +55 | CE - cURus - cULus - CCSAus | |
| FX 20-0824 A | 204 | 204 | 88 | 23 | 85 | 24 DC 50/60 Hz | 342 | 8.2 | 42 | -10 +55 | CE - UR - cULus - CCSAus | |
| FX 25-20230 A | FF 25 | 250 | 250 | 116 | 24 | 230/270 | 230 ac 50/60 Hz | 0.140/0.160 | 32/36 | 50.0/55.0 | -10 +55 | CE - cURus - cULus - CCSAus |
| FX 25-2010A | 250 | 250 | 116 | 24 | 230/270 | 115 ac 50/60 Hz | 0.280/0.270 | 31/31 | 50.0/55.0 | -10 +55 | CE - cURus - cULus - CCSAus | |
| FX 25-2024 A | 250 | 250 | 117 | 24 | 230 | 24 DC 50/60 Hz | 1.3 | 31 | 59 | -10 +55 | CE - cURus - cULus - CCSAus | |
| FX 25-25230 A | FF 25 | 250 | 250 | 113 | 24 | 360/400 | 230 ac 50/60 Hz | 0.300/0.382 | 67/87 | 63.3/68.1 | -10 +70 | CE |
| FX 25-2510 A | 250 | 250 | 113 | 24 | 250/270 | 115 ac 50/60 Hz | 0.54/0.65 | 50/64 | 66.0/69.2 | -10 +70 | CE | |
| FX 32-50230 A | FF 32 | 325 | 325 | 151 | 24 | 455/503 | 230 ac 50/60 Hz | 0.310/0.350 | 70/85 | 57.0/60.0 | -10 +55 | CE - cURus - cULus - CCSAus |
| FX 32-50110 A | 325 | 325 | 151 | 24 | 445/485 | 115 ac 50/60 Hz | 0.68/0.73 | 74/83 | 58.0/60.0 | -10 +55 | CE - cURus - cULus - CCSAus | |
STANDARD CERTIFICATIONS
ON REQUEST
